F2304: High-Performance Central Processor Module for Industrial Automation and Safety Systems

1. Core Features

• Powerful Computing Capability
  • Equipped with NXP MPC8572E processor (1GHz), 512MB DDR2 RAM, and 2GB Flash storage, enabling complex control logic and high-speed data processing.
  • Supports ultra-fast sampling (e.g., 25μs per channel in some models) for rapid response and precise detection.
• High Reliability & Safety

  • F2304 Built with industrial-grade components, tested for harsh environments (operating temperature: -40°C to +85°C, IP67-rated).

  • Redundant design options (single or dual-channel) for enhanced system availability, with automatic failover during faults.
  • Complies with IEC 61508 SIL 3 safety standards, ideal for critical applications like emergency shutdowns and fire detection.
• Rich Connectivity & Scalability
  • Communication interfaces: RS-232, RS-485, Ethernet, and PCIe expansion slots for seamless integration with other devices/networks.
  • Multi-channel I/O:  F2304 Supports digital input/output for sensors/actuators, with some models enabling 4-axis motion control.
• Flexible Programming & Configuration
  • Programmed via ELOP II tools using a PC (PADT) for offline code generation, monitoring, and documentation.
  • Digital outputs configurable for immediate or delayed error reporting to suit diverse scenarios.
  •

2. Functions & Applications

• Key Functions
  • Data Acquisition & Analysis: Real-time signal collection from field devices, comparison with stored reference values, and control execution.
  • Safety Logic Processing: Implements emergency shutdowns, safety interlocks, and other critical logic to protect personnel/equipment.
  • Statistical Reporting: Generates reports on measured values (max/min/average) for PLCs to optimize production.
• Typical Use Cases
  • Oil & Gas: Monitor reactor temperature/pressure to prevent leaks/explosions.
  • Power Generation: Manage grid equipment for load distribution and fault isolation.
  • Metallurgy: Control blast furnaces/rolling mills for continuous production.
  • Pharmaceuticals/Food: Track production line environmental parameters to meet GMP standards.

3. Technical Specifications

4. Product Advantages

• High Performance & Low Latency: Fast sampling and real-time processing meet stringent industrial automation demands.
• High Availability: Redundant design and noise immunity ensure long-term stability.
• Scalable Integration: Supports multiple protocols and expansion interfaces for easy system upgrades.
• Safety Compliance: Meets global standards for critical infrastructure protection.
• F2304 PDF
• F2304 size：20*15*12CM
• F2304 weight：0.8KG

5. Application Examples

• Petrochemical Plant: Used F2304 to monitor tank levels/pressure, enabling automatic interlock protection against spills.
• Nuclear Power Station: Deployed redundant  F2304 systems to control coolant pumps, ensuring reactor safety.
• Automotive Factory: Leveraged 4-axis motion control to optimize welding robot paths, boosting productivity.
